OWON SPE3102 Programmable DC Power Supply- 30V, 10A

The OWON SPE3102 Programmable DC Power Supply is a versatile and reliable instrument designed for a wide range of electronic testing and development applications. With an output voltage range of 0-30V and a current range of 0-10A, it provides ample power for powering and testing various electronic circuits and devices. This programmable power supply offers precise control over voltage and current settings, allowing users to tailor the output to their specific requirements with high accuracy and stability.

Featuring a user-friendly interface and intuitive controls, the SPE3102 makes it easy to set up and adjust voltage and current parameters. It also offers programmable features, enabling users to create and save custom voltage and current profiles for repeated testing or experimentation. Additionally, the power supply is equipped with overvoltage, overcurrent, and overtemperature protection mechanisms, ensuring the safety of both the equipment under test and the user.

With its robust construction and reliable performance, the OWON SPE3102 Programmable DC Power Supply is suitable for use in educational laboratories, research facilities, production lines, and electronic repair workshops. Whether powering basic circuits or testing complex electronic systems, this power supply offers the versatility, precision, and reliability needed for demanding electronic testing and development tasks.

Features:

1. Ultra-thin body, portable and easy to use, SMPS Based
2. 30V, 10A Adjustable- 200W constant power design, wide application range
3. Over voltage/current protection
4. Power-on automatic output setting function, suitable for unattended occasions
5. Intelligent temperature control fan cooling reduces noise
6. 4 groups of Memory shortcut parameters for quick output
7. USB Device communication port, support SCPI
8. Constant voltage CV/constant current CC mode effectively protects the circuit

Specifications:

Item Type:	Programmable DC Power Supply
Model No.:	SPE3102
Output Voltage(V)	0 – 30
Channels	1
Output Current (A)	10
Rated output power	200W
Noise	≤3mVrms
Load Regulation Voltage	≤30mV
Load Regulation Current	≤20mA
Power Regulation Voltage	≤30mV
Power Regulation Current	≤20mA
Setting Resolution Voltage	10mV
Setting Resolution Current	1mA
Operating Temperature (°C)	0-40
Shipping Weight	1.96 kg
Shipping Dimensions	35 × 14 × 20 cm

Package Includes:

1 x OWON SPE3102 Programmable DC Power Supply

1 x Power Cord

1 x USB Cable for SCPI Communication

1 x Fuse

1 x Quick Guide
