SmartElex Multiplexer Breakout – 8 Channel -74HC4051

(0) 0 Reviews 0 Orders 0 Wish listed

₹139.00

Quantity :

Total price :

(Tax : )

Overview
Reviews

SmartElex Multiplexer Breakout – 8 Channel (74HC4051)

The SmartElex Multiplexer Breakout brings the versatile 74HC4051 to your projects, providing easy access to all its pins and features. This 8-channel analog multiplexer/demultiplexer enables you to transform four I/O pins into eight selectable signals, perfect for applications such as driving multiple LEDs or monitoring several potentiometers.

The 74HC4051 can operate as either a multiplexer or a demultiplexer, offering eight channels for routing input and output signals. By digitally controlling three select lines (S0-S2), you can choose between eight different binary combinations, allowing you to route a common signal to any of the independent I/O channels.

On one side of the breakout, you’ll find the control signals (E, S0-S2) and the common input/output (Z) pins. The other side provides access to all eight independent I/O channels (Y0-Y7). Both sides are equipped with supply and ground connections (VCC, VEE, GND), ensuring straightforward integration into your circuits.

Features:

8-Channel Multiplexer/Demultiplexer: Easily route a common signal to one of eight selectable channels.
Versatile Functionality: Suitable for driving LEDs, monitoring sensors, or connecting various inputs.
Binary Selection Control: Use three select lines (S0-S2) to choose from eight binary combinations.
Easy Access: All control and I/O pins are conveniently broken out for simple connections.
Common Input/Output: Features a common pin (Z) for streamlined signal routing.
Dual-Sided Design: Access to control signals and independent I/O on separate sides for flexibility.
Power Connections: Includes supply (VCC, VEE) and ground (GND) connections for easy integration.
